CV-A

Model

Thread Connection
( PT )

Operating Pressure

Cracking Pressure
( kgf/cm² )

Flow
( l/min )

Weight
( kg )

CV-03A

3/8”

210 kgf/cm²
( 3000 PSI )

05 : 0.5

50 : 5.0

40

0.22

CV-04A

1/2”

60

0.34
