PV 063
GA 3 R M 1 A 0 N
a b
c d e f g
h i j
a. Model
Name : PV
b. Displacement
: 16, 20, 23, 28, 32, 40, 46, 56, 65, 63, 71, 80, 92, 110, 125,
140,180, 210,270
c. Control
Device : A0, LN, LS, LC, GM, GA, GJ, GR, GB, GC, HM, HA,
HJ, HR, HB, HC, HQ, HK, BQ, VM, VA, VJ, VQ, VK, FV, FG, PM, PA, PJ, PR,
PH, PQ, PS
d. Pressure
Adj. Range :
2: 10~140 bar
3: 35~250 bar
4: 40~280 bar
5: 50~315 bar
6: 70~350 bar
e. Direction of
Rotation :
R: clockwise
L: counter clockwise
f.
Mounting :
V: FKM (fluor-caoutchouc)
g. Thread Code:
1:BSPP
2:PT
3:UNF(SAE)
7:ISO 6149 (M)
h. Through Drive
& 2nd Pump : A
i.
Voltage :
none
A: AC 110V ( 50/60Hz )
B: AC 110V ( 60Hz)
C: AC 220V ( 50/60Hz )
D: AC 220V ( 60Hz )
E: DC 12V
F: DC 24V
j: seal type
j.
Seals :
N: NBR
V: viton
E: ethylen-propylene
|
