P
16 - A 3 - ED - F - R - S - 01
a
b - c d - e - f - g - h
- i
a.
Model Name : P
b. Delivery
: 08, 10, 13, 16, 22, 36, 46, 70, 100
c.
Control Type :
A:pressure compensating type
B:remote pressure control type
HL:load sensing control type
d. Pressure
(bar) :
0: 15 ~ 45 (for P08-P46)
1: 20 ~ 75
2: 25 ~ 145
3: 30 ~ 215
4: 30 ~ 280 (for P70-P100)
e. Control
Type ( Additional ) * Only for HL Type :
EDG:electro-hydraulic proportional control type
EDPV(EDPFC):Pressure, flow proportional control type
f. Mounting
Flange :
F:SAEJ 744
g. Direction
of Rotation ( Viewed from Shaft Side ) :
R:clockwise direction
L:counter clockwise
h. Drive
Shaft :
none:standard
S:spline
i. Thread
for P08-P70 :
01:PT
20:SAE
30:BSPP
40:NPT
Thread for
P100 :
02:PT
20:SAE
32:BSPP
42:NPT
|
